25 CFM / 7.5 HP Air Compressor Champion Refrigerated Air Dryer

Original price was: $2,279.00.Current price is: $2,051.25.

SKU: CGD25 Category: Champion Refrigerated Compressed Air Dryers

Description
Shipping Information

Product Description

Built to meet ISO 8573.1 class 4 standard—–Max P.D.P. 38 F
Installed separator to help trap solids >10 micron
Built-in cold filter 3 Micron—–Coalesce water droplet
Protected from corrosion with Epoxy powder paint
Easier to service—–Reduces maintenance cost of the refrigerated Champion air dryer
This compressed air dryer features a multiple copper tube heat exchanger for energy efficiency.

Take a look at the refrigerated air dryer for 35 CFM air compressors for an option with a slightly higher level of horsepower.

2 Year Warranty on Compressor
5 Year Warranty on Heat Exchange

View Brochure

Specifications	Value
RATED CFM CAPACITY	25
PRESSURE DEW POINT	38 F
CONTROLLER LEVEL	1
MAXIMUM PSIG	250
PSIG PRESSURE DROP	3
REFRIGERANT TYPE	134A
DRAIN TYPE	PNEUMATIC
IN / OUT CONNECTIONS	3/4″ NPT
H.P.	1/6
NEMA RATING	1
VOLTAGE	115
HERTZ	60
PHASE	1
HEIGHT (IN)	22
WIDTH (IN)	16
DEPTH (IN)	15
WEIGHT (LB)	88
